The KF20 internal combustion counterbalanced forklift is suitable for outdoor working conditions, such as construction sites, mines, ports and other locations with relatively harsh operating environments that demand high power and load-carrying capacity from the forklift. It can be used for loading and unloading heavy goods like construction materials and ores, as well as transporting and stacking cargo on uneven ground.
| Model | KF20 |
| Series | KF |
| Description | Internal Combustion Counterbalance Forklift |
| Power Type | Diesel |
| Weight(kg) | 3400kg |
| Engine Brand | Xinchai |
| Rated Power(kW) | 36.8 |
| Rated Load Capacity(kg) | 2000 |
| Load Center Distance(mm) | 500 |
| Max. Lifting Height(mm) | 3000 |
| Free Lift Height(mm) | 130 |
| Mast Tilt Angle(°) | 6°/12° |
| Min. Turning Radius(mm) | 2290 |
| Gradeability (Full Load / Empty Load)(%) | 15%/20% |
| Min. Ground Clearance (mm) | 110 |
| Overall Length(mm) | 2520 |
| Overall Width(mm) | 1170 |
| Overall Height(mm) | 2145 |
| Wheelbase(mm) | 1650 |
| Track Width(mm) | 970/980 |
| Fork Dimensions(mm) | 1070*125*40 |
