KOTAI has not only maintained its exclusive durability and reliability ,but also armed their 5 Ton Diesel Forklift with new fuction,aiming to promote its operational capacity ,security and efficiency.We can see this new achievement from its uniquely improved uploading system,the design of cab,operating lever and the car body.
Parameters
| Model | KF50 |
| Lift capacity | 5000kg |
| Rated Load center distance | 600mm |
| Maximum lifting height | 3000mm |
| Free lifting height | 190mm |
| Gate frame inclination angle(front/rear) | 6°/12° |
| Maximum lifting speed(full load/no load) | 500/520mm/s |
| Maximum descent speed(full load/no load) | 360/400mm/s |
| Maximum driving speed(full load/no load) | 25/30km/h |
| Minimum turning radius | 3320mm |
| Gradeability(full load)(full load/no load) | 20/25% |
| Maximum hook traction force | 70kN |
| Overall weight | 8330kg |
| Length (without fork) | 3480mm |
| Width | 2000mm |
| Gate frame height | 2500mm |
| Overall height of overhead guard | 2450mm |
| Shelf height | 1440mm |
| Overall height at maximum lift | 4430mm |
| Minimum ground clearance | 200mm |
| Wheelbase | 2250mm |
| Tire distance(Front/Rear) | 1470/1710mm |
| Fork size(L*W*H) | 1220x150x60mm |
Features
Fuses,relays and other electric elements are integrated into a control box,which makes the maintenance and inspection work more convenient.
On the basis of increasing the radiator,we use the aluminum for heat sink which has emhanced significantly the cooling effect.
Plus large double muffler has superior noise reduction effect.
The new suspension system,adjustable seat,allowing the driver to feel more comfortable and reducing fatigue during long time operations.
5 Ton Diesel Forklift Step area is about 1.5 times of similar forklift.while the step height is lower ,more conducive to the driver on forklift.
